Angle Fire Fiber®
Safe, Efficient, and Effective Side-Firing Laser Technology
Overview of Angle Fire Fibers
Angle Fire Fibers are special side-firing laser fibers. They are made for treating benign prostatic hyperplasia (BPH) and other surgeries that need sideways laser energy. The angled tip sends laser energy between 70° and 90°, helping doctors reach areas that regular straight fibers can’t. This approach supports minimally invasive procedures and aligns with FDA-recognized medical laser standards, offering safer outcomes and improved control in confined anatomical areas.
These fibers are built with a strong SMA-905 connector, a tough outer jacket, and a protective coating. They work with high-power laser systems at all wavelengths. This means better results, shorter surgeries, and less risk for patients. Learn more about laser surgery applications and how angled laser fibers support enhanced clinical precision.
Available in single use:
600/660 natural jacket fiber, outer diameter 1050 micron, damage-resistant SMA 905 connector, 2250 micron outer diameter at the tip.
Other dimensions available by request, including:
550/600 micron fiber
600/720 micron fiber
Sterile single-use configuration:
MF 600/660 HCNN (hard clad / natural color jacket, NA 0.22, 3 meters, 1050 micron outer diameter, 2250 micron capillary tip, SMA 905 connector, Luer lock).
Contact us to request a sample or discuss OEM integration
KEY FEATURES OF ANGLE-TIPPER LASER FIBERS
- Angled Tip: Provides 70°–90° lateral energy delivery
Faster surgical performance than flat-tip fibers
Smooth tissue gliding with low friction tip design
Designed for high-power lasers across all wavelengths
Damage-resistant SMA 905 connector or Luer Lock
Available in 600/660 µm, 550/600 µm, and 600/720 µm core sizes
Sterile, single-use, hard-clad construction with natural color jacket
Biocompatible materials, made in the USA, engineered in Germany
TECHNICAL SPECIFICATIONS OF SURGICAL ANGLE FIBERS
| Parameter | Value |
|---|---|
| Emission Angle | 70°–90° side-firing (angled tip) |
| Core Diameter | 200–600 µm (available options) |
| Wavelength Support | 1900–2200 nm (Ho:YAG and Thulium lasers) |
| Jacket Material | Blue Nylon |
| Sterility | Single-use or reusable |
| Connector Type | SMA-905, Luer Lock, OEM custom |
| Length Options | 2.5 m standard or custom-length available |
Downloadable Brochure
CERTIFICATIONS: FDA 510(K): K 124003 - ISO 13485:2016 - CE MARKING
Request a Quote
Need a side-firing fiber built for precision, control, and safety?
Reach out today to request a quote or customize a version for your system.
