DOME TIP LASER FIBERS™
Scope-Protective. Stronger Tip. Zero Energy Loss
DOME TIP FIBER OVERVIEW
Our Dome Tip Laser Fibers are designed for precision in delicate procedures like benign prostatic hyperplasia (BPH) treatment and other urology surgeries. These curved, side-firing fibers deliver laser energy with high control while minimizing trauma to surrounding tissue.
The 360° dome-shaped tip allows smooth gliding in tight areas such as the upper portion of the prostate, improving accuracy and reducing procedural complications. This design mimics the effectiveness of TURP (transurethral resection of the prostate) while offering the benefits of minimally invasive laser technology.
Whether in contact or non-contact mode, the fiber’s durability and performance meet the demands of modern high-power laser systems.
🔗 Learn more about BPH treatment techniques
🔗 See FDA regulations for medical laser devices
🔗 Explore clinical research on laser prostate surgery
Contact us to request a sample or discuss OEM integration
Key Features of dome tip fiber
Atraumatic Dome Tip Fiber for safer navigation and reduced trauma
Collimated energy beam with zero internal reflection loss
200× stronger tip durability thanks to fire-polished microcrack prevention
Smooth energy delivery optimized for Ho:YAG laser systems
Blue jacket, silicone/tefzel construction for enhanced flexibility and safety
Compatible with all FDA-cleared surgical laser platforms
SMA 905 connectors standard
Single-use, sterile configurations with short lead times
Available Sizes & Model Specs of dome tip fibers
| Model Code | Core Diameter | Outer Diameter | Length | Jacket / Material | Use Type | Connector |
|---|---|---|---|---|---|---|
| MF 200 Series SBT-DT | 200 Series | 430 µm | 3 m | Silicone / Tefzel | Single-use | SMA 905 |
| MF 272/300 SBT-DT | 272 / 300 | 450 µm | 3 m | Silicone / Tefzel | Single-use | SMA 905 |
| MF 365/400 SBT-DT | 365 / 400 | 580 µm | 3 m | Silicone / Tefzel | Single-use | SMA 905 |
| MF 550/605 SBT-EF* | 550 / 605 | 780 or 880 µm* | 3 m | Silicone / Tefzel | Single-use | SMA 905 |
| MF 600/660 SBT-EF | 600 / 660 | 920 µm | 3 m | Silicone / Tefzel | Single-use | SMA 905 |
| MF 800/880 SBT-EF | 800 / 880 | 1180 µm | 3 m | Silicone / Tefzel | Single-use | SMA 905 |
| MF 1000/1100 SBT-EF | 1000 / 1100 | 1500 µm | 3 m | Silicone / Tefzel | Single-use | SMA 905 |
*Please specify 780 or 880 µm OD when ordering 550/605 model.
Downloadable Brochure
Applications of dome tip fibers
CERTIFICATIONS: FDA 510(K): K 124003 - ISO 13485:2016 - CE MARKING
