HOLMIUM SURGICAL LASER FIBERS
Medical Holmium Fibers engineered for precision surgical procedures
Fill in our contact form for more information
HOLMIUM LASER FIBER OVERVIEW
Holmium laser fibers from MED FIBERS are designed for precise surgical procedures in urology, ENT, and general surgery. Available in 200μm and 365μm, these fibers are CE and FDA certified, ensuring safety, reliability, and global medical compliance.
Optimized for Ho:YAG laser systems (wavelength ~2100 nm), these fibers deliver outstanding performance in stone fragmentation, stricture treatment, and tissue ablation. They minimize thermal damage while providing high durability.
Built with robust materials and engineered for low insertion loss, MED FIBERS holmium fibers are available in various core sizes and protective jackets. Choose between reusable or disposable options to meet your clinical or OEM needs.
Contact us to request a sample or discuss OEM integration
Key Features of Holmium Laser Fibers
- High power tolerance for Ho:YAG laser compatibility (~2100 nm)
Precise energy delivery with minimal beam divergence
Low back reflection and high damage threshold
Multiple core diameters: 200 µm to 1000 µm
Jacket options: white or blue nylon, ETFE, PU
SMA-905, Luer Lock, or custom OEM connector options
Available sterile, non-sterile, reusable or disposable
Tapered tips, polished ends, and custom markings available
Technical Specifications
| Parameter | Value |
|---|---|
| Wavelength Range | 1900–2200 nm (optimized for Ho:YAG) |
| Core Diameter | 200–1000 µm (multiple options) |
| Numerical Aperture | 0.22 ± 0.02 |
| Jacket Materials | Blue/White Nylon, PU, ETFE |
| Connector Options | SMA-905 / Luer Lock / OEM Custom |
| Length | Standard 2.5 m or customized |
| Sterility | Single-use or Reusable, sterile/non-sterile |
Holmium Laser Fiber Size Options
All fibers are available in both single-use and reusable versions, with blue jacket construction for durability and flexibility.
| Fiber Code | Core Diameter (µm) | Outer Diameter (µm) |
|---|---|---|
| 200/240 | 200 µm | 400 µm |
| 272/300 | 272 µm | 450 µm |
| 365/400 | 365 µm | 580 µm |
| 550/605 | 550 µm | 780 or 880 µm |
| 600/660 | 600 µm | 920 µm |
| 800/880 | 800 µm | 1180 µm |
| 1000/1100 | 1000 µm | 1500 µm |
- Compatible with all major Ho:YAG laser systems
- OEM connector customization available (SMA-905, Luer Lock, etc.)
Downloadable Brochure
Applications
Need a Custom Solution?
We’re here to help. Whether you’re interested in a custom fiber optic configuration, requesting a sample, or have specific technical questions — just fill out the form below.
We will respond within 1–2 business days.
